Spektrum Firma 3660-4000Kv 4-Pole Sensorless Brushless Motor Overview

The Spektrum® Firma™ 3650 4000Kv Brushless Motor is a great replacement motor for the 1/8 scale INFRACTION® 4X4 3S BLX All-Road RTR running on 2-3S LiPo power. This motor features a 4-pole rotor design, CNC machined aluminum housing, insulated high purity copper windings, and a high-quality alloy steel 5mm output shaft for durability and smooth rotation. The motor also includes preinstalled 4mm gold-plated bullet connectors for easy installation.

Key Features

• 2-3S LiPo Power Compatible
• 4-pole Rotor Design
• 5mm Allow Steel Output Shaft
• Pre-installed 4mm Gold-plated Bullet Connectors

In The Box

• (1) Firma 3660-4000Kv 4-Pole Sensorless Brushless Motor: 5mm

Download Firma 3660-4000Kv 4-Pole Sensorless Brushless Motor Innstruction Manual

Specifications

Connector Type: 4mm Bullet
Connector Wire Length: 1.96" (50 mm)
Motor Size: 3660-4000Kv
Motor Type: Brushless
Number of Poles: 4
Outer Diameter: 1.41" (36 mm)
Product Length: 2.36" (60 mm)
Product Weight: 300g
RPM/Volt (Kv): 4000Kv
Shaft Diameter: 0.19" (5 mm)
Shaft Length: 0.87" (22 mm)
Voltage: 7.4v - 11.1v
