Technical data
- Wingspan: 1444mm (56.8in)
- Length: 1168mm (45.9 in)
- Flying weight: 2400-2600 gr
- Wing area: 35.2 dm2
- Wing loading: 70g/dm2
- Wing type: Naca airfoils
- Covering type: V-kote film
- Spinner size: Plastic 58mm (included)
- Radio: 4 channel minimum (not included)
- Servo: 5 standard servo: 2 aileron; 1 elevator; 1 rudder; 1 throttle (not included)
- Recommended receiver battery: 4.8-6V / 800-1200mAh NiMH (not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: .46-.55 / 2-stroke (not included)
- - Motor: brushless outrunner Dualsky Tuning Combo 50E (not included)
- Gravity CG: 70mm (2.7in) Back from  the leading edge of the wing, at the fuselage
- Control throw Ailerons: Low: 8mm up/down, 10% expo; High: 10mm up/down, 10% expo
- Control throw Elevators: Low: 8mm up/down, 12% expo; High: 10mm up/down, 12% expo
- Control throw Rudder: Low: 25mm right/left, 15% expo; High: 40mm right/left, 15% expo
- Experience level: Intermediate
- Plane type: Low wing sport

RECOMMENDED MOTOR AND BATTERY SET UP
- Motor:.Dualsky Tuning Combo 50E
- Lipo cell: Ace Power 6S 22.2V 5400mAh 60C (not included)
- Esc: 50-70A (not included)




Features
- Designed for compatibility with both GP and EP flight
- Extremely lightweight laser-cut all-wood construction
- All hardware included





SKU PHN-PH006
Barcode # 9313890011355
Brand Phoenix Models
Shipping Weight 3.0000kg
Shipping Width 0.430m
Shipping Height 0.120m
Shipping Length 1.120m
Shipping Cubic 0.057792000m3
