This is the Dualsky 2308C 1800kv brushless motor. It is suitable for Aircraft

Specification

  • RPM/V (KV): 1800
  • Turns: 9
  • Weight (g): 47
  • Dimensions: 28.8x24.9mm
  • Diameter of Shaft (mm): 3.175
  • No of Cells: 2S or 3S LiPo
  • Slots, Poles: 12N14P
  • Idle Current (Io) @ 10V: 1
  • Max Efficiency Current (A): 15
  • Max Torque [N*M]: 0.159
  • Max Burst Current (15S) [A]: 25
  • Max Power (W) [15S]: 200
  • Mounting Holes Pitch: 16/16mm
  • Recommended ESC: XC-22-LITE or XC2512BA
  • Propeller: 2S: 10x5E, 9x6E/ 3S: 6x5.5E, 7x3E
  • Class: Wings and Little Jets
  • Input Connectors: GC3.5
  • Ri(mOhm): 68
SKU DSXM51644
Barcode # 6941047116443
Brand Dualsky
Shipping Weight 0.0800kg
Shipping Width 0.050m
Shipping Height 0.040m
Shipping Length 0.090m
Shipping Cubic 0.000180000m3
