Features

Less weight but more thrust
10 ounces lighter than the FA-120
Turns an APC 16x6 at 9,000 rpm
13mm Muffler threads

Needed To Complete

Propeller: 16x6

Overview

Only Saito could put 1.25 cubic inches of power into a 1.00-size case. Not only is the FA-125 lighter and more powerful than the FA-120 it replaces, its unique size allows modelers to apply its awesome power to a wide variety of airplane sizes. It will work with anything from .90-size sport aerobats all the way up to 1.20-size sport and IMAC planes.

With 10 fewer ounces and .05 more cubic inches than the FA-120 it replaces, the FA-125A gives new meaning to the term “escape velocity.” Just bolt one to the nose of favourite 90 size plane and you’ll see what we mean.

Specifications

Displacement	1.25 cu. in. (20.52 cc)
Bore:	1.24 in (31.7mm)
Stroke:	1.02 in (26.0mm)
Type:	4-Stroke
Cylinders:	Single
Cylinder Type:	AAC
Crank Type:	Dual Ball Bearing
Fuel Type:	Glow
Muffler Type:	Cast
Muffler Weight:	2.89 oz (80 g)
Mounting Dimensions	119 x 60 x 127mm
Engine (Only) Weight:	21.87 oz (620 g)
Carb Type:	2 Needle
Total Weight	24.69 oz (700 g)
Crankshaft Threads	M8 x 1.25mm
Benchmark Prop:	APC 16X6 @ 9000 rpm
Prop Range:	15x7 - 17x6
RPM Range:	1800 - 10000 rpm
