Instruction

  • Applicable to TB40.
  • Fully CNC-machined from 6061-T6 aluminum alloy.
  • The motor mount features an additional guide pulley, which effectively guides the belt for stable parallel operation, enhances the transmission force between the belt and pulley, and ensures the belt's service life.

Specifications

  • TB40 motor mounting bracket x 1
  • Round head hexagon socket screws x 4 (M2.5 x 6mm)
  • Half-head hexagon
  • socket screws x 4 (M3 x 6mm) TB40 motor pulley x 1 (Φ6 x Φ7.8 x 8.5mm)
  • Washers x 2 (Φ2.5 x Φ4.4 x 1mm)
  • 682XZZ bearings x 2 (Φ2.5 x Φ6 x 2.6mm)
  • Round head hexagon socket screw x 1 (M2.5 x 10mm)
SKU HB40B018XXW
Barcode # 4713413735334
Brand Align
Shipping Weight 0.0300kg
Shipping Width 0.080m
Shipping Height 0.030m
Shipping Length 0.130m
Shipping Cubic 0.000312000m3
