Instruction Manual



SPECIFICATION:
-   Wingspan:1,950 mm (76.77in).
-   Length: 1,297 mm (51.06 in).
-   Weight: 3.2 – 3.5 kg (7.04 – 7.7 lbs).
-  Wing area: 53.8 dm2.
-  Wing loading: 59.5 g/dm2.
-  Wing type: USA – 35B.
-  Servo mount: 42mm x 21mm.
-  Gear type: Aluminium Hi-grade for main gear and spring wire for tail gear (included).

Parts listing required (not included):
-   Radio : 04 channels.
-   Servo : 04 – 05 servos.
-   Engine: 46 – 55   2 stroke.
-   Motor: Brushless outrunner 1000-1800W, 800KV.
-   Propeller: Suit with your engine.

Recommended Motor and Battery set up (not included):
-   Motor:  RIMFIRE.55.
-   Lipo cell: 6 cells 4,000-5,000mAh.
-   ESC: 60A.

ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER.

SKU BH-04A
Brand Black Horse Models
Shipping Weight 8.0000kg
Shipping Width 0.400m
Shipping Height 0.300m
Shipping Length 1.500m
Shipping Cubic 0.180000000m3
