This high-quality ARRMA MEGA ESC unit (with integrated LiPo protector) will provide consistent and safe power control in your ARRMA vehicle.

Includes

1x ARRMA MEGA Brushed ESC

Features

Fitted with reliable IC3 connector - Capable of running 2S LiPo or 6 or 7 cell NiMh, this MEGA ESC has over-voltage protection for safe voltage management when under heavy operating conditions - Cool-looking integrated red anodized heatsink for increased heat dissipation - Durable motor and battery connection cables for safe and reliable power transfer - Waterproof power switch - Strong and durable red nylon case with dedicated chassis mount tabs for additional secure fit  - Etched 'ARRMA' livery for cool looks and quality assurance

Specifications

Battery usage: 7.2v (6 Cell) NiMh Stick Pack, 8.4v (7 Cell) NiMh Stick Pack, 7.4V (2S) Lipo
Low Voltage Cut-Off (LVC): 3.2V per cell
Thermal Protection Temperature: 95°C / 203°F
BEC Voltage: 5V
BEC Current: 2A
ESC Length: 47mm / 1.85"
ESC Height: 21mm / 0.83"
ESC Width: 34mm / 1.34"
ESC Weight: 70g / 2.47oz
Receiver Wire Length: 160mm / 6.3"
Battery Wire Length: 90mm / 3.54"

Compatibility

  • 1/10 GRANITE BRUSHED 4X4
  • 1/10 SENTON BRUSHED 4X4
  • 1/8 INFRACTION BRUSHED 4X4
  • 1/8 TYPHON BRUSHED 4X4
SKU ARA390288
Barcode # 5052127035637
Brand Arrma
Shipping Weight 0.1400kg
Shipping Width 0.090m
Shipping Height 0.070m
Shipping Length 0.130m
Shipping Cubic 0.000819000m3
