Instruction Manual



SPECIFICATION:
-       Wingspan : 2,250 mm (88.58 in).
-       Length : 1,675 mm ( 65.94 in).
-       Weight : 5.5kg (12.1lbs).
-       Wing area: 59.7 dm2.
-       Wing loading: 92.1g/dm2.
-       Wing type: USA 35-B Airfoil.
-       Servo mount: 42mm x 21mm.
-       Gear type: Aluminium Hi-grade for main gear
         and spring wire for tail gear (included).

Parts listing required (not included):
-       Radio: 06 channels.
-       Servo: 08 servos.
-       Engine: 20 – 30cc Gas.
-        Motor: Brushless outrunner 1800-2300W, 450KV.
-       Propeller: Suit with your engine.

Recommended motor and battery set up (not included):
-       Motor:  RIMFIRE.120.
-       Lipo cell: 6 cells 4,000-5,000mAh.
-       ESC: 80A.
-       Receiver battery: 6V/ 1200-2000mAh NiMH.

ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED WITH ORACOVER

SKU BH-162
Brand Black Horse Models
Shipping Weight 3.0000kg
Shipping Width 0.400m
Shipping Height 0.300m
Shipping Length 1.500m
Shipping Cubic 0.180000000m3
